Victron Orion 24/12-40 – ORI241240021
MPN Number:
ORI241240021
Victron Orion 24/12-40 DC-DC Converter – ORI241240021
The Victron Orion 24/12-40 DC-DC Converter, known as ORI241240021, is designed for high power applications, providing reliable voltage conversion from 24V to 12V. This non-isolated converter is perfect for charging a 12V starter or accessory battery within a 24V system, ensuring robust performance and user-friendly operation. Its compact design and efficient functionality make it an essential component for various automotive and marine applications, emphasizing convenience and efficiency for users.
Product Features
Remote On-Off Connector
The Victron Energy ORI241240021 features a remote on-off connector that simplifies the installation process by removing the need for high current switches in the input wiring. This allows users to operate the converter with a low-power switch or via the engine run/stop switch, enhancing usability and safety.
Adjustable Output Voltage
With the ability to adjust the output voltage, this converter can be tailored to meet specific application needs. Users can set the output to a range between 10 to 15V, making it versatile for various settings. This adaptiveness ensures maximum efficiency for all connected devices.
Parallel Connection Capability
The ORI241240021 can be connected in parallel with up to five units to increase output current, a feature that significantly enhances its power delivery capability. This flexibility supports scaling in higher power applications, making it ideal for larger systems.
High Efficiency Rating
This model boasts an impressive efficiency rating of 95%, ensuring minimal energy loss during operation. Such high efficiency translates to enhanced performance in real-world conditions, maximizing battery longevity and energy savings.
Compact and Easy to Install
The compact design of the Victron Energy ORI241240021 makes it easy to install in limited spaces. The delivery includes insulated Faston connectors for straightforward setup, ensuring that users can quickly implement the converter without hassle.
How It Works
The Victron Orion 24/12-40 operates by converting a 24V input to a regulated 12V output through its internal circuitry. This process ensures stable voltage output, making it suitable for charging applications or powering 12V devices that require reliable energy supply.
Input Voltage Handling
This converter manages an input voltage range of 18-35V, providing users with flexibility in connecting various 24V battery systems while maintaining performance under varying conditions.
Efficiency and Temperature Control
With fan-assisted, temperature-controlled cooling, the Victron Orion 24/12-40 effectively dissipates heat during operation. This feature supports the converter’s longevity by preventing overheating during extensive use.
Output Connection Options
The converter supports multiple output connection options, including Faston tabs and M6 bolts, accommodating diverse connectivity needs for different applications. This versatility enhances project adaptability and ease of integration.
Specifications
| Input Voltage Range | 18-35 V |
| Output Voltage | 13.2 V (Adjustable) |
| Efficiency | 95% |
| Continuous Output Current | 40 A |
| Max Output Current | 55 A |
| Cooling Method | Fan Assisted (Temperature Controlled) |
| Weight | 0.85 kg (1.9 lbs) |
| Dimensions (hxwxd) | 65 x 88 x 185 mm (2.6 x 3.5 x 7.3 inches) |
| Operating Temperature Range | -20 to 55 °C |
| Remote On-Off Feature | Yes |
