Philadelphia Solar 144 Half Cells Black/Silver 550w Solar Panel – PS-M144(HCBF)-550W
MPN Number:
PS-M144(HCBF)-550W
Philadelphia Solar 144 Half Cells Black/Silver 550W Solar Panel
The Philadelphia Solar PS-M144(HCBF)-550W is a high-performance solar panel featuring 144 half-cell technology for superior energy efficiency and durability. With a sleek black and silver design, this panel offers an optimal solution for residential, commercial, and industrial solar installations. Built with precision engineering and advanced materials, it ensures reliable performance and maximum energy output.
Key Features
High Power Output
Designed to deliver up to 550 W of power, the Philadelphia Solar PS-M144(HCBF)-550W provides exceptional performance for large-scale energy projects.
Advanced Half-Cell Technology
This solar panel utilizes 144 half-cell technology, which minimizes resistive losses, improves shading tolerance, and enhances overall energy production efficiency.
Durable and Reliable
Engineered to withstand heavy snow loads of up to 5400 Pa and wind loads of up to 2400 Pa, it ensures longevity in a variety of environmental conditions.
Enhanced Efficiency
With a module efficiency of up to 21.3%, this solar panel optimizes energy generation, reducing installation costs and maximizing returns.
Sleek Aesthetic
The black and silver finish complements modern architecture, making it an ideal choice for residential rooftops and high-visibility installations.
How It Works
Half-Cell Technology
The 144 half-cell configuration reduces power loss and enhances performance by splitting the solar cells, allowing for greater efficiency and improved energy yield.
Optimized Shading Tolerance
The panel design ensures better performance in shaded conditions, making it ideal for complex installations.
Robust Build
Constructed with high-quality materials, the panel features tempered glass and an anodized aluminum frame, ensuring durability and reliability in harsh weather conditions.
Specifications
| Specification Title | Specification Value |
| Model Number | PS-M144(HCBF)-550W |
| Nominal Max. Power (Pmax) | 550 W |
| Opt. Operating Voltage (Vmp) | 41.5 V |
| Opt. Operating Current (Imp) | 13.25 A |
| Open Circuit Voltage (Voc) | 49.8 V |
| Short Circuit Current (Isc) | 13.94 A |
| Module Efficiency | 21.3% |
| Dimensions | 2279 × 1134 × 35 mm |
| Weight | 28.6 kg |
| Cell Type | Monocrystalline |
| Cell Arrangement | 144 [12 × (6 × 2)] |
| Front Glass | 3.2 mm tempered glass with anti-reflective coating |
| Frame | Anodized aluminum alloy |
| Junction Box | IP68, 3 bypass diodes |
| Operating Temperature | -40°C ~ +85°C |
| Max. System Voltage | 1500 V |
| Max. Series Fuse Rating | 20 A |
| Application Classification | Class A |
| Warranty | 25 years linear performance warranty |
Certification
- IEC 61215
- IEC 61730
- ISO 9001:2015
- ISO 14001:2015
- ISO 45001:2018
For detailed specifications, refer to the product datasheet.
