Mission Solar 385W PV Solar Panel – MSE385SX5R

The Mission Solar MSE385SX5R is a high-performing 385W solar panel designed for reliability and efficiency. This panel, part of Mission Solar’s prestigious range, boasts a class-leading power output with a tolerance of -0 to +3%. It’s crafted to meet the demands of residential, commercial, and utility applications and certified for exceptional durability and performance in diverse environments.

Product Features

Exceptional Power Output

The Mission Solar MSE385SX5R provides a remarkable power output of up to 385W, ensuring efficiency and reliability. Incorporating advanced photovoltaic technology, it maximizes energy production under various sunlight conditions.

Robust American Manufacture

This solar panel is designed and assembled in San Antonio, Texas, offering true American quality. Mission Solar’s commitment to local manufacturing supports national industry standards, providing a product that exceeds expectation in durability and performance long-term.

High Durability and Load Resistance

Built to withstand extreme weather conditions, this solar panel is tested for up to 5,400 Pa front load and 3,600 Pa back load. It meets UL 61730 standards, ensuring reliable operation through harsh environments for enhanced longevity.

PID Resistance and Advanced Technology

Featuring Passivated Emitter Rear Contact (PERC) and 6-busbar cell technology, the MSE385SX5R enhances efficiency and offers PID resistance, ensuring sustained performance and effective power output over its lifespan.

Comprehensive Certification and Warranty

The panel’s performance and safety are validated through certifications with UL 61730, IEC 61215, and IEC 61730 standards. It guarantees degradation of less than 2% in the first year and 0.58% annually thereafter, offering 84.08% capacity by year 25 with BAA compliance ideal for government projects.

How It Works

The Mission Solar MSE385SX5R operates utilizing advanced solar technologies to convert sunlight into electricity. This process involves several key components, working together to ensure efficient energy conversion and high system performance.

Solar Cells

The solar panel consists of 66 P-type mono-crystalline silicon cells arranged in a 6×11 format. These high-efficiency cells capture and convert solar energy with minimal loss, contributing to the overall efficiency of the system.

Junction Box with IP67 Rating

Equipped with a protection class IP67 junction box, the panel is safeguarded against moisture and dust, extending its operating life. The addition of 3 bypass-diodes further enhances its reliability and minimizes energy loss.

Robust Frame and High-Quality Glass

The panel is framed in anodized material and topped with 3.2mm tempered low-iron glass. This construction enhances strength and solar transmittance while ensuring resilience against environmental stressors.

Specifications

Power Output (Pmax)	375-385W
Efficiency	18.8%-19.3%
Tolerance	0/+3%
Short Circuit Current (Isc)	10.85-10.97A
Open Circuit Voltage (Voc)	44.64-45.03V
Rated Current (Imp)	10.26-10.42A
Rated Voltage (Vmp)	36.56-36.93V
Fuse Rating	20A
System Voltage	1,000V
Operating Temperature Range	-40°C to +85°C
Dimensions	1,907mm x 1,044mm x 40mm
Weight	22 kg (49 lbs.)
