BYD MLTK-36 520-545W Solar Panel Overview

The BYD MLTK-36 520-545W is a high-performance solar panel engineered with advanced monocrystalline cell technology. Designed for durability and efficiency, this panel delivers up to 545 W of power, ensuring optimal energy generation for residential and commercial applications. Its black and silver design enhances aesthetics while maximizing functionality.

Key Features

High Power Output

With a maximum output of 545 W, the BYD MLTK-36 520-545W solar panel ensures exceptional performance, even in challenging environmental conditions.

Advanced Monocrystalline Technology

The panel uses 144 monocrystalline cells, offering superior efficiency and energy yield compared to traditional solar technologies.

Durable Design

Built to withstand extreme weather conditions, this solar panel features a robust frame and high-quality materials for long-lasting performance.

Optimized for Versatility

The BYD MLTK-36 520-545W is compatible with a wide range of installation setups, making it ideal for various project scales.

Enhanced Temperature Coefficient

With a low-temperature coefficient, this panel ensures stable performance even in high-temperature environments.

How It Works

Efficient Energy Conversion

The BYD MLTK-36 520-545W utilizes advanced monocrystalline cells to capture sunlight and convert it into electricity with high efficiency.

Durable Construction

Featuring high-transparency tempered glass and a robust aluminum alloy frame, this panel is built for longevity and reliable operation.

Optimized Performance

Equipped with a high-performance junction box and bypass diodes, the panel minimizes power loss and enhances energy yield in partial shading conditions.

Specifications

Specification Title	Specification Value
Model Number	MLTK-36 520-545W
Nominal Max. Power (Pmax)	545 W
Module Efficiency	21.3%
Dimensions	2278 x 1134 x 35 mm
Weight	27.8 kg
Cell Type	Monocrystalline PERC
Cell Arrangement	144 (6 x 24)
Front Glass	3.2 mm tempered glass with anti-reflective coating
Frame	Anodized aluminum alloy
Operating Temperature	-40°C ~ +85°C
Max. System Voltage	1500 V
Junction Box	IP68, 3 bypass diodes
Connector	MC4-compatible

Certification

This solar panel meets industry-leading standards, including IEC 61215, IEC 61730, and UL 61730, ensuring quality and safety for all installations.

Compatibility

The BYD MLTK-36 520-545W is compatible with most inverters and energy storage systems, making it a versatile choice for various solar projects.
